Taoxing Semi-automatic Pneumatic Flat Screen Printing Machine TX-400M for Umbrella
Taoxing Semi-automatic Pneumatic Flat Screen Printing Machine TX-400M for Umbrella
This series of curved screen printers are suitable for high-precision printing of surface patterns and characters on various cosmetic containers, pharmaceutical containers, food containers, electronic devices, toys, and cases.
| Categories | Semi-Automatic Flat Screen Printing Machine |
|---|---|
| Brand | TAOXING Screen Printing Machines Manufacturer |
| Model | TX-400S |
| Max. Printing Area | 360*250mm |
| Max. screen frame size | 580*350mm |
| Printing Speed | 1200 pcs/hour |
| Air pressure | 5-6Bar |
| Application | Umbrella |
| Dimensions | 960*900*1380mm |
| Weight | 120KG |
| Voltage | 220V/50HZ/20W |
| FOB port | Shanghai or Ningbo |
| Terms of Payment | D/P, T/T |
| Update Time | Oct 16,2024 |
Detail Information
Introduction
Application
This series of curved screen printers are suitable for high-precision printing of surface patterns and characters on various cosmetic containers, pharmaceutical containers, food containers, electronic devices, toys, and cases.
1.Low MOQ: It can meet your low qty demand very well.
2.Good Service : We treat clients business as our own business.
3.Good Quality :We have strict QC quality control system .Good reputation in the market.
4.Fast & Cheap Delivery: We have big discount from shipping forwarder (Long Contract).
Specification
Main parameters
Model:TX-400M
Maximum Print Area: 360*250mm
Maximum Screen Frame Size: 580*350mm
Printing Speed: 1200 pcs /hour
Electric Source: 220V/50HZ/20W
Air Pressure: 5Bar
Dimensions: 960*900*1380mm
Weight: 120KG
Features and Performance
1.Microprocessor control each function with high automation and easy operation;
2.4-digit auto counter built in;
3.Cylindrical/conical printing function available;
4.Auto ink squeegee and flooding, worktable elevating to assure easy operation and consistent print quality;
5.Printing stroke and speed are adjustable to meet different requirements;
6.Fine adjustment available on squeegee left/right position to make substrate alignment easy and exact;
7.Fine adjusted available on worktable up/down and plane angle, and frame front/rear, left/right and up/down with high printing precision.
Printing samples
